Falcon Overland 8-Way 12V Power Distribution Block

$229.00
Tax included. Shipping calculated at checkout.

Our 8 way distributor allows you to add 4 MEGA fuse and 4 MIDI fuse inputs/outputs to your Falcon Distribution System.


Perfect for connecting your batteries and/or distributing power to a large inverters and multiple chargers and other accessories that draw between 20A to 350A.

If 8 outputs aren’t enough, you can bolt as many as you like together.

You can place the joining busbars on the left or right of the module to build your perfect system.


Dimensions

Without busbars: 210 mm W × 136 mm D × 85 mm H

With busbars: 245 mm W × 136 mm D × 85 mm H


Specifications (All Ratings are Continuous Ratings)


High-Current Outputs/Inputs

- 4 x 350A

- 4 x 135A

Performance Limits

- Max combined current: 400A

- Max pass-through current: 400A

Busbar Size

- 120mm² Tin-Coated Copper Busbars
